This guide walks through building a simplified subname registrar: a minimal smart contract that lets users register and renew subnames under a parent name you own. It demonstrates the core pattern that all ENSv2 registrars follow, including the production ETH Registrar.

The registrar built here is based on the ETH Registrar, but heavily simplified: commit-reveal, oracle-based pricing, grace periods, and referral tracking are stripped away, leaving the essentials of availability checks, flat-fee ERC20 payments, registration, and renewal.

By the end you will know how a registrar interfaces with an ENSv2 registry at the contract level, how the two are connected and authorized, how to interact with them through a client library like viem, and how to index the events they emit.

Architecture

In ENSv2, registries and registrars have distinct responsibilities. The registry (a Permissioned Registry or UserRegistry) stores names, manages ERC1155 tokens, and enforces permissions. Since each registry is its own contract, the subnames it manages form their own NFT collection, distinct from .eth names and from every other subname project. The registrar is a separate contract that sits in front of the registry and handles business logic: pricing, payment collection, availability checks, and any registration constraints.

The registrar calls registry.register() to create names and registry.renew() to extend them. For this to work, the registry owner must grant the registrar two roles on ROOT_RESOURCE (the registry-wide resource, whose roles apply to every name in the registry; see Enhanced Access Control):

The registrar itself does not store names or manage tokens. It is a thin gatekeeper that validates inputs, collects payment, and delegates to the registry.

Project Setup

This tutorial uses Foundry. Install the ENSv2 contracts directly from their GitHub repository:

forge init simple-subname-registrar && cd simple-subname-registrar
forge install ensdomains/contracts-v2

The repository brings its own OpenZeppelin checkout along as a git submodule, so no separate OpenZeppelin install is needed. Add both remappings to foundry.toml so the import paths used below resolve:

remappings = [
    "@ensdomains/contracts-v2/=lib/contracts-v2/contracts/src/",
    "@openzeppelin/contracts/=lib/contracts-v2/contracts/lib/openzeppelin-contracts/contracts/",
]

You will build the contract in src/SimpleSubnameRegistrar.sol.

Building the Contract

Imports and Role Bitmap

Start the file with the pragma and imports:

// SPDX-License-Identifier: MIT
pragma solidity ^0.8.20;

import {SafeERC20, IERC20} from "@openzeppelin/contracts/token/ERC20/utils/SafeERC20.sol";
import {IPermissionedRegistry} from "@ensdomains/contracts-v2/registry/interfaces/IPermissionedRegistry.sol";
import {IRegistry} from "@ensdomains/contracts-v2/registry/interfaces/IRegistry.sol";
import {RegistryRolesLib} from "@ensdomains/contracts-v2/registry/libraries/RegistryRolesLib.sol";

Next, define REGISTRATION_ROLE_BITMAP as a file-level constant, between the imports and the contract declaration. It determines what permissions each name owner receives at registration. We use the same bitmap as the ETH Registrar:

uint256 constant REGISTRATION_ROLE_BITMAP =
    RegistryRolesLib.ROLE_SET_SUBREGISTRY
    | RegistryRolesLib.ROLE_SET_SUBREGISTRY_ADMIN
    | RegistryRolesLib.ROLE_SET_RESOLVER
    | RegistryRolesLib.ROLE_SET_RESOLVER_ADMIN
    | RegistryRolesLib.ROLE_CAN_TRANSFER_ADMIN;

This grants name owners the ability to change their resolver, set up a child registry for sub-subnames, and transfer their name. The _ADMIN variants of the two setter roles let owners delegate those permissions to other accounts. ROLE_CAN_TRANSFER_ADMIN works differently: it is the transfer permission itself, an admin-only role with no non-admin counterpart. See EAC roles for full details.

Contract Shell

The contract stores its configuration as immutable values set at deployment. All five parameters are fixed for the lifetime of the registrar: which registry it manages, which token it accepts, where payments go, the annual price, and the minimum registration duration.

contract SimpleSubnameRegistrar {
    using SafeERC20 for IERC20;

    error NameNotAvailable(string label);
    error NameNotRegistered(string label);
    error InvalidOwner();
    error DurationTooShort(uint64 duration, uint64 minimum);

    event NameRegistered(
        uint256 indexed tokenId, string label, address owner,
        uint64 duration, uint256 price
    );
    event NameRenewed(
        uint256 indexed tokenId, string label,
        uint64 duration, uint64 newExpiry, uint256 price
    );

    IPermissionedRegistry public immutable REGISTRY;
    IERC20 public immutable PAYMENT_TOKEN;
    address public immutable BENEFICIARY;
    uint256 public immutable PRICE;
    uint64 public immutable MIN_DURATION;

    constructor(
        IPermissionedRegistry registry,
        IERC20 paymentToken,
        address beneficiary,
        uint256 price,
        uint64 minDuration
    ) {
        REGISTRY = registry;
        PAYMENT_TOKEN = paymentToken;
        BENEFICIARY = beneficiary;
        PRICE = price;
        MIN_DURATION = minDuration;
    }

PRICE is denominated in the payment token's smallest unit (e.g., for USDC with 6 decimals, a price of 5_000_000 means $5/year). MIN_DURATION is in seconds.

All functions in the following sections go inside this contract body.

Checking Availability

To check whether a label is available for registration, query the registry's getState() function. It returns a State struct containing the name's status, expiry, latest owner (latestOwner), token ID, and resource. A name is available if its status is AVAILABLE (either never registered or expired).

The getState() function accepts an anyId: a labelhash, token ID, or resource. For a fresh lookup by label, use the labelhash (keccak256(bytes(label))).

    function isAvailable(string calldata label) public view returns (bool) {
        IPermissionedRegistry.State memory state =
            REGISTRY.getState(uint256(keccak256(bytes(label))));
        return state.status == IPermissionedRegistry.Status.AVAILABLE;
    }

    function getPrice(uint64 duration) public view returns (uint256) {
        return PRICE * duration / 365 days;
    }

getPrice() pro-rates the annual price by duration. For example, if PRICE is 5 USDC and duration is six months (15768000 seconds), the cost is ~2.5 USDC. Integer division truncates toward zero, so pick PRICE and MIN_DURATION such that the minimum charge (PRICE * MIN_DURATION / 365 days) stays well above zero; otherwise short registrations become free.

Registering Names

The register() function validates inputs, collects payment, and delegates to REGISTRY.register(). The registry handles all token minting and role assignment internally.

    function register(
        string calldata label,
        address owner,
        address resolver,
        uint64 duration
    ) external returns (uint256 tokenId) {
        if (!isAvailable(label)) revert NameNotAvailable(label);
        if (owner == address(0)) revert InvalidOwner();
        if (duration < MIN_DURATION) revert DurationTooShort(duration, MIN_DURATION);

        uint256 price = getPrice(duration);
        PAYMENT_TOKEN.safeTransferFrom(msg.sender, BENEFICIARY, price);

        tokenId = REGISTRY.register(
            label,
            owner,
            IRegistry(address(0)),
            resolver,
            REGISTRATION_ROLE_BITMAP,
            uint64(block.timestamp) + duration
        );

        emit NameRegistered(tokenId, label, owner, duration, price);
    }

A few things to note about the REGISTRY.register() call:

• label is the subname label only (e.g., "sub" for sub.nick.eth), not the full name
• IRegistry(address(0)) means no child registry is set; the owner can set one later via setSubregistry() if they want sub-subnames
• resolver is the address of a Permissioned Resolver proxy (or any contract implementing the resolver interface), typically deployed per account via the Verifiable Factory; the owner can change it later with setResolver() since they hold ROLE_SET_RESOLVER
• expiry is an absolute Unix timestamp, not a duration
• The returned tokenId is the ERC1155Singleton token minted to the owner

Renewing Names

Renewal extends a name's expiry without changing ownership or permissions. Anyone can renew any name (not just the owner), which matches the ETH Registrar's behavior.

    function renew(string calldata label, uint64 duration) external {
        if (duration < MIN_DURATION) revert DurationTooShort(duration, MIN_DURATION);

        uint256 labelId = uint256(keccak256(bytes(label)));
        IPermissionedRegistry.State memory state = REGISTRY.getState(labelId);

        if (state.status != IPermissionedRegistry.Status.REGISTERED) {
            revert NameNotRegistered(label);
        }

        uint256 price = getPrice(duration);
        PAYMENT_TOKEN.safeTransferFrom(msg.sender, BENEFICIARY, price);

        uint64 newExpiry = state.expiry + duration;
        REGISTRY.renew(labelId, newExpiry);

        emit NameRenewed(state.tokenId, label, duration, newExpiry, price);
    }
}

The registry's renew() function accepts an anyId (here we pass the labelhash) and an absolute newExpiry timestamp. The registry enforces that newExpiry >= oldExpiry, so the expiry can only increase.

The closing brace after renew() completes the contract. The full file is below; forge build should compile it cleanly.

// SPDX-License-Identifier: MIT
pragma solidity ^0.8.20;

import {SafeERC20, IERC20} from "@openzeppelin/contracts/token/ERC20/utils/SafeERC20.sol";
import {IPermissionedRegistry} from "@ensdomains/contracts-v2/registry/interfaces/IPermissionedRegistry.sol";
import {IRegistry} from "@ensdomains/contracts-v2/registry/interfaces/IRegistry.sol";
import {RegistryRolesLib} from "@ensdomains/contracts-v2/registry/libraries/RegistryRolesLib.sol";

uint256 constant REGISTRATION_ROLE_BITMAP =
    RegistryRolesLib.ROLE_SET_SUBREGISTRY
    | RegistryRolesLib.ROLE_SET_SUBREGISTRY_ADMIN
    | RegistryRolesLib.ROLE_SET_RESOLVER
    | RegistryRolesLib.ROLE_SET_RESOLVER_ADMIN
    | RegistryRolesLib.ROLE_CAN_TRANSFER_ADMIN;

contract SimpleSubnameRegistrar {
    using SafeERC20 for IERC20;

    error NameNotAvailable(string label);
    error NameNotRegistered(string label);
    error InvalidOwner();
    error DurationTooShort(uint64 duration, uint64 minimum);

    event NameRegistered(
        uint256 indexed tokenId, string label, address owner,
        uint64 duration, uint256 price
    );
    event NameRenewed(
        uint256 indexed tokenId, string label,
        uint64 duration, uint64 newExpiry, uint256 price
    );

    IPermissionedRegistry public immutable REGISTRY;
    IERC20 public immutable PAYMENT_TOKEN;
    address public immutable BENEFICIARY;
    uint256 public immutable PRICE;
    uint64 public immutable MIN_DURATION;

    constructor(
        IPermissionedRegistry registry,
        IERC20 paymentToken,
        address beneficiary,
        uint256 price,
        uint64 minDuration
    ) {
        REGISTRY = registry;
        PAYMENT_TOKEN = paymentToken;
        BENEFICIARY = beneficiary;
        PRICE = price;
        MIN_DURATION = minDuration;
    }

    function isAvailable(string calldata label) public view returns (bool) {
        IPermissionedRegistry.State memory state =
            REGISTRY.getState(uint256(keccak256(bytes(label))));
        return state.status == IPermissionedRegistry.Status.AVAILABLE;
    }

    function getPrice(uint64 duration) public view returns (uint256) {
        return PRICE * duration / 365 days;
    }

    function register(
        string calldata label,
        address owner,
        address resolver,
        uint64 duration
    ) external returns (uint256 tokenId) {
        if (!isAvailable(label)) revert NameNotAvailable(label);
        if (owner == address(0)) revert InvalidOwner();
        if (duration < MIN_DURATION) revert DurationTooShort(duration, MIN_DURATION);

        uint256 price = getPrice(duration);
        PAYMENT_TOKEN.safeTransferFrom(msg.sender, BENEFICIARY, price);

        tokenId = REGISTRY.register(
            label,
            owner,
            IRegistry(address(0)),
            resolver,
            REGISTRATION_ROLE_BITMAP,
            uint64(block.timestamp) + duration
        );

        emit NameRegistered(tokenId, label, owner, duration, price);
    }

    function renew(string calldata label, uint64 duration) external {
        if (duration < MIN_DURATION) revert DurationTooShort(duration, MIN_DURATION);

        uint256 labelId = uint256(keccak256(bytes(label)));
        IPermissionedRegistry.State memory state = REGISTRY.getState(labelId);

        if (state.status != IPermissionedRegistry.Status.REGISTERED) {
            revert NameNotRegistered(label);
        }

        uint256 price = getPrice(duration);
        PAYMENT_TOKEN.safeTransferFrom(msg.sender, BENEFICIARY, price);

        uint64 newExpiry = state.expiry + duration;
        REGISTRY.renew(labelId, newExpiry);

        emit NameRenewed(state.tokenId, label, duration, newExpiry, price);
    }
}

Deploying and Authorizing

Set Up the UserRegistry

The registrar needs a registry to register into. If your parent name does not have one yet, two setup steps are required: deploy a UserRegistry proxy via the Verifiable Factory, then point your parent name at it with setSubregistry() on the parent registry.

For the first step, follow Deploying a Registry Proxy; the ProxyDeployed event in the receipt gives you the proxy address (userRegistryAddress below). Choose the roleBitmap passed to initialize() carefully: granting a role later via grantRootRoles() requires holding that role's _ADMIN variant, so the bitmap must include at least ROLE_REGISTRAR_ADMIN and ROLE_RENEW_ADMIN for the authorization step below to succeed.

The second step is what connects the new registry to the ENS hierarchy. The Universal Resolver finds subnames by walking getSubregistry() calls down from the root, so until your parent name points at the UserRegistry, names registered in it mint tokens but never resolve. You hold ROLE_SET_SUBREGISTRY on your name from registration, so this call needs no extra setup:

import { keccak256, toHex, parseAbi } from 'viem'

const permissionedRegistryAbi = parseAbi([
  'function setSubregistry(uint256 anyId, address subregistry)',
])

// Point the parent name at the UserRegistry
// (here: nick.eth, so this runs on the .eth registry)
await wallet.writeContract({
  address: ethRegistryAddress,
  abi: permissionedRegistryAbi,
  functionName: 'setSubregistry',
  args: [BigInt(keccak256(toHex('nick'))), userRegistryAddress],
})

The wallet object in the TypeScript snippets on this page is a viem wallet client; its setup is shown in Client Integration below. The protocol contract addresses (like ethRegistryAddress) are listed in the Deployments table.

Deploy the Registrar

The registrar is a plain contract (not a proxy), so deployment is straightforward. You need:

• The address of your UserRegistry (from the previous step)
• An ERC20 payment token address (on a testnet, deploy your own mintable mock ERC20; any token implementing transferFrom/approve works)
• A beneficiary address for receiving payments
• The annual price in the token's smallest unit
• A minimum registration duration in seconds

SimpleSubnameRegistrar registrar = new SimpleSubnameRegistrar(
    IPermissionedRegistry(userRegistryAddress),
    IERC20(usdcAddress),
    beneficiaryAddress,
    5_000_000,      // 5 USDC per year (6 decimals)
    30 days          // minimum 30-day registration
);

For example, deploying with Foundry:

forge create src/SimpleSubnameRegistrar.sol:SimpleSubnameRegistrar \
    --rpc-url $RPC_URL --private-key $PRIVATE_KEY --broadcast \
    --constructor-args $USER_REGISTRY $PAYMENT_TOKEN $BENEFICIARY 5000000 2592000

The last two arguments are the price (5 USDC with 6 decimals) and the minimum duration (30 days in seconds). Passing a raw private key is acceptable for testnet experiments; in general, follow Foundry's key management best practices (encrypted keystores via cast wallet import, hardware wallets for production).

Grant Roles to the Registrar

After deployment, the registry owner must grant the registrar ROLE_REGISTRAR and ROLE_RENEW on ROOT_RESOURCE. Without these roles, calls to registry.register() and registry.renew() will revert.

In Solidity:

registry.grantRootRoles(
    RegistryRolesLib.ROLE_REGISTRAR | RegistryRolesLib.ROLE_RENEW,
    address(registrar)
);

Or via viem:

const ROLE_REGISTRAR = 1n << 0n
const ROLE_RENEW = 1n << 16n

await wallet.writeContract({
  address: userRegistryAddress,
  abi: [{
    name: 'grantRootRoles',
    type: 'function',
    stateMutability: 'nonpayable',
    inputs: [
      { name: 'roleBitmap', type: 'uint256' },
      { name: 'account', type: 'address' },
    ],
    outputs: [{ name: '', type: 'bool' }],
  }],
  functionName: 'grantRootRoles',
  args: [ROLE_REGISTRAR | ROLE_RENEW, registrarAddress],
})

Trust works in both directions: the roles that remain on ROOT_RESOURCE define how much subname owners must trust you. See Configuration Patterns for the managed versus emancipated trade-off, and Emancipation for how owners can verify your registry's setup.

Client Integration

Once the registrar is deployed and authorized, users interact with it via standard writeContract calls. Here is a complete example using viem. ENSv2 is currently deployed on Sepolia, so the clients target that chain; in a browser app you would create the wallet client with custom(window.ethereum) instead of a private key account.

import { createPublicClient, createWalletClient, http } from 'viem'
import { privateKeyToAccount } from 'viem/accounts'
import { sepolia } from 'viem/chains'

const registrarAddress = '0x...'   // your deployed SimpleSubnameRegistrar
const paymentTokenAddress = '0x...' // ERC20 payment token (e.g., USDC)

const account = privateKeyToAccount(process.env.PRIVATE_KEY as `0x${string}`)
const client = createPublicClient({ chain: sepolia, transport: http() })
const wallet = createWalletClient({ account, chain: sepolia, transport: http() })

const simpleRegistrarAbi = [
  {
    name: 'isAvailable', type: 'function', stateMutability: 'view',
    inputs: [{ name: 'label', type: 'string' }],
    outputs: [{ name: '', type: 'bool' }],
  },
  {
    name: 'getPrice', type: 'function', stateMutability: 'view',
    inputs: [{ name: 'duration', type: 'uint64' }],
    outputs: [{ name: '', type: 'uint256' }],
  },
  {
    name: 'register', type: 'function', stateMutability: 'nonpayable',
    inputs: [
      { name: 'label', type: 'string' },
      { name: 'owner', type: 'address' },
      { name: 'resolver', type: 'address' },
      { name: 'duration', type: 'uint64' },
    ],
    outputs: [{ name: 'tokenId', type: 'uint256' }],
  },
  {
    name: 'renew', type: 'function', stateMutability: 'nonpayable',
    inputs: [
      { name: 'label', type: 'string' },
      { name: 'duration', type: 'uint64' },
    ],
    outputs: [],
  },
] as const

Check Availability and Price

const available = await client.readContract({
  address: registrarAddress,
  abi: simpleRegistrarAbi,
  functionName: 'isAvailable',
  args: ['sub'],
})

const oneYear = BigInt(365 * 24 * 60 * 60)
const price = await client.readContract({
  address: registrarAddress,
  abi: simpleRegistrarAbi,
  functionName: 'getPrice',
  args: [oneYear],
})

Register a Subname

Before calling register(), the caller must approve the registrar to spend the payment token:

import { erc20Abi } from 'viem'

// Approve the registrar to spend the payment token
await wallet.writeContract({
  address: paymentTokenAddress,
  abi: erc20Abi,
  functionName: 'approve',
  args: [registrarAddress, price],
})

// Register sub.nick.eth
const hash = await wallet.writeContract({
  address: registrarAddress,
  abi: simpleRegistrarAbi,
  functionName: 'register',
  args: ['sub', ownerAddress, resolverAddress, oneYear],
})

To confirm the registration worked, check availability again; it should now return false:

const stillAvailable = await client.readContract({
  address: registrarAddress,
  abi: simpleRegistrarAbi,
  functionName: 'isAvailable',
  args: ['sub'],
})
console.log(stillAvailable) // false

Once the owner sets records on the resolver, the name resolves like any other ENS name (e.g., via viem's getEnsAddress).

Renew a Subname

// Approve payment for renewal
await wallet.writeContract({
  address: paymentTokenAddress,
  abi: erc20Abi,
  functionName: 'approve',
  args: [registrarAddress, price],
})

// Extend sub.nick.eth by one year
await wallet.writeContract({
  address: registrarAddress,
  abi: simpleRegistrarAbi,
  functionName: 'renew',
  args: ['sub', oneYear],
})

Events and Indexing

A single register() call triggers events from two contracts: the registrar and the underlying registry. If you are building an indexer, you need to listen to both.

From the registry (emitted inside REGISTRY.register()):

Renewals follow the same pattern: renew() emits the registrar's NameRenewed and the registry's ExpiryUpdated. Indexing only the registrar's events would miss renewals performed by other ROLE_RENEW holders directly on the registry.

For the full event reference, parameter details, and indexing patterns, see Indexing ENSv2.

Troubleshooting

Next Steps

The SimpleSubnameRegistrar covers the core registration pattern. Here are common extensions you might add:

• Commit-reveal: prevent front-running by requiring a commitment before registration. See how the ETH Registrar implements this.
• Allowlists or NFT-gating: restrict who can register by checking token balances or merkle proofs in register().
• Custom role bitmaps: use different REGISTRATION_ROLE_BITMAP values for different registration tiers (e.g., premium names get fewer restrictions).
• Infinite-duration claims: for permanent subnames, pass type(uint64).max as the expiry instead of computing it from a duration. renew() and the ROLE_RENEW grant become unnecessary, but abandoned names never return to the available pool; removing one then requires the operator to hold ROLE_UNREGISTER, a trust tradeoff expiry-based recycling avoids.
• Grace periods: keep expired names renewable for a window before they become available to others.
• Custom registries: for deeper customization, build your own registry by extending PermissionedRegistry directly. See Registry Template.
